Introducing the 2025 version of ARCHLine.XP, a leading BIM software brand used worldwide.
This year's release comes with numerous innovative features in building and interior design, point cloud management, and MEP tools, making the design process significantly faster.
Point cloud surveys are becoming increasingly common. New wall and door/window detection tools enable accurate detection of walls and windows from point clouds, reducing the time needed to create a BIM model to a fraction of the time.
The new command exports model geometry and BIM data to Revit in RVT file format.
Connect to designers using Revit directly! By communicating between Revit and ARCHLine.XP, you can avoid conversion errors and data loss while saving time.
The bsDD service is a vital tool for BIM professionals, containing not only items but also properties with values.
Using it, professionals can standardise their workflows, ensuring consistency and quality of their data.
Try the new automatic floor plan generator, which allows you to quickly and easily create floor plans, reducing your design time to a fraction of the time! Easily customise the different layout suggestions to get the layout you want faster.
In the cut-away 3D view, you can set exactly which parts of the multi-storey building you want to see.
On more complex models, it makes it easier to select and edit the element to be modified.
In the new version, you can easily try out a photo-realistic image of the scene with different backgrounds, thanks to the editable backgrounds in the render images.
Transparent areas are marked with an alpha channel, so you can insert different backgrounds behind the image on the floor plan, which you can scale and adjust.
The new Object templates allow you to create and save complete furniture designs in the library, which you can reuse later.
Items are flexible, interchangeable, customizable and you can even give them unique display settings in your projects.
From now on, no mathematical calculations are needed to accurately position objects in height.
With the new feature, you can simply enter the height of the top of the object and it will automatically be placed in the correct position - especially handy when positioning ceiling or pendant lights.
The enhanced render engine in ARCHLine.XP supports the use of IES lights, which provide realistic lighting effects.
The feature is simple to set up and spotlights automatically adapt to the selected IES light source.
When you start the paint bucket command, you can select the materials in the project or available from the library.
In the 3D window, you can select the surfaces you want to texture and the program will automatically apply the selected material.
With section visibility filters, you can easily control which elements appear in a view, based on categories or custom filters.
For example, you can use a custom filter to create a section view in which the point cloud is not visible.
Select an item and edit its main parameters quickly and easily in the editable list that appears!
This feature is available in the 2D and 3D views for most architectural elements in ARCHLine.XP.
The styles panel has been redesigned to include more features. The new panel displays the current style and a list of recently used styles has been added. In the search box, the styles you are looking for are displayed at any name match.
The new Schedule by Selection command places the schedule of the selected elements on the drawing at the same time, sorted by type.
This makes the tedious documentation process much quicker and easier to understand.
The new tiling tool can handle up to three materials at once, allowing you to create more realistic parquet floors and more exciting wall coverings.
It's the ideal choice for designing detailed and spectacular interiors.
